40 Foot Fence Cargo Semi Trailer

Description

Description：

YUHANG factory 40 foot fence cargo semi trailer is widely used, mainly for loading poultry livestock, vegetables, bagged cement, packing cartons or other bulk goods.

The fence trailer is equipped with a fence structure on the basis of the flatbed semi trailer, and the height of the side wall is 600-2000mm for you to choose.

3 axle 40 foot fence trailer is our main best-selling vehicle, which has achieved success in many countries such as: Southeast Asia, the Middle East, Africa and South America market.

Our fence cargo semi trailers are equipped with twist locks to transport standard 20ft, 40ft, 45ft and 48ft containers. One type of vehicle has different usages and truly creates more value for customers.

40 foot fence cargo semi trailer for sale

3 axle fence trailer with best price

China first-class fence trailer manufacturer–YUHANG

Advantage：

● The frame adopts the space frame structure formed by integral welding of the longitudinal beam passing through the transverse beam, which increases the carrying capacity of the fence trailer and does not deform or break under heavy load.

● The robot automatically tracks the welding fence cargo semi trailer throughout the whole process, the solder joints are dense and strong, and the welding quality is high and flawless.

● Equipped with new type mechanical suspension system, it can balance the load between the axles and reduce the friction between the tire and the ground.

● The accessories are world-renowned brand products with long service life and low maintenance cost.

● YUHANG has its own physical factory and supplies fence trailers directly to customers with a competitive price.

Specification:

Manufacturer: YUHANG 40 Foot Fence Cargo Semi Trailer

Dimension(mm): 12500x2550x3450mm

Trailer Sides: 1800mm

Loading Capacity: 30-80 ton

Main Beam: height 500mm, upper plate 14mm, middle plate 8mm, bottom plate 16mm, made of Q345B steel

Side Beam: 16mm or 18mm Q235 channel steel

Platform: 3mm-thick checkered plate

Axle: 3 axle*13T/16T*FUWA/BPW brand

Tire: 12 units*12.00R22.5 or 315/80R22.5

Rim: 9.00-22.5 or 9.75-22.5

Suspension: mechanical suspension

Spring Leaf: 90(w)mmx13(thickness)mmx10 layers or 100mmx12mmx12 layers

King Pin: JOST brand 2.0 or 3.5 inch (bolted or welded)

Landing Gear: JOST brand double speed, external 28 ton

Twist Locks: 4/8/12 sets (lifting or screw type)

Brake Valve: WABCO valve

ABS: optional

Color: optional

Light: LED light

Voltage: 24V

Socket: 7-pin Socket (for 7 wire harness)

Painting: polyurethane anti-corrosion paint

Accessories: one standard tool box, spare tire carrier

Shipping Terms: bulk carrier, Ro-Ro ship or container

---
