4 Axle End Dump Trailer

Description

Description：

4 axle end dump trailer for sale with good price, it is generally used to transport construction materials, coal, ore, earthwork, grain and other loose goods.

The tipper semi trailer is powered by the tractor engine, and uses the hydraulic lifting system to lift the cargo compartment to the designed angle so that the cargo in the box can slide out to complete the entire unloading process.

YUHANG has done a lot of technical upgrades and accessories updates, so as to ensure that the 4 axle end dump trailer has more efficient operating capabilities.

At the same time, tipper semi trailer have different shapes and types, and we can design and customize tipper trailer according to your actual transportation needs.

4 axle end dump trailer for sale

80 ton tipper semi trailer with best price

China’s largest dump truck trailer factory–YUHANG

Advantage：

● The main beam of the 4 axle end dump trailer adopts a double-web design structure, which has a stronger bearing capacity and is not easy to deform and break when carrying heavy cargos.

● U-shaped box body design style, large cross-sectional area, low center of gravity, high loading and unloading efficiency, safe and stable operation data.

● The outer side of the tipper trailer box body is reinforced with ribs to reduce the effective impact force of the cargo, and has good compression resistance and prolongs the service life.

● Adopting HYVA hydraulic cylinder lifting system, the lifting capacity is stronger, the height is higher, the lifting is more stable, and no rollover will occur.

● The heavy-duty widened and thickened leaf spring suspension has good shock absorption effect and can adapt to more rugged and complex road conditions.

Specification:

Brand: YUHANG 4 Axle End Dump Trailer

Dimension: 10500mmx2500mm x3500mm

Main Beam: height 500mm, upper plate 14mm, middle plate 8mm, lower plate 16mm, material high strength steel

Bottom Platform: 6mm thick checkered plate

Sidewall: 4mm

Lifting System: HYVA lifting cylinder

Axle: 4 axle, 13T/16T, FUWA/BPW brand

Rim: 8.0-20 or 9.00-20

Tire: 16 units, 8.25R20/10.00R20/11.00R20/12R22.5

Suspension: heavy duty mechanical suspension

Spring Leaf: 90(w)mmx13(thickness)mmx10 layers

King Pin: JOST brand 2 or 3.5 inch detachable type

Landing Gear: JOST brand 28t

ABS: optional

Brake System: WABCO valve

Light: LED light

Voltage: 24V

Socket: 7-pin Socket (for 7 wire harness)

Painting: polyurethane anti-corrosion paint

Accessories: one standard tool box, spare tire carrier

Shipping Terms: bulk carrier or Ro-Ro ship

---
