4 Axle Side Wall Trailer Price

Description

Description：

YUHANG 4 axle side wall trailer price is better than other factory, it is widely used in the logistics and transportation industry, mainly loaded with cement bags, steel plates, grain or other bulk goods that are easy to fix.

Our 4 axle side wall trailer is very competitive in quality and performance, and has been successfully sold to many countries, such as: Southeast Asia, the Middle East, Africa and South America.

The side wall trailer adopts container twist locks, which can transport 20 feet, 40 feet, 45 feet standard containers. A variety of loading purposes, better service for customers.

We are a professional 4 axle side wall trailer price manufacturer with our own physical factory, and the side wall height can be customized according to customer needs.

4 axle side wall trailer price for sale

80 ton sidewall semi trailer

China famous 4 axle side wall trailer manufacturer

Advantage：

● 4 axle side wall trailer uses high-strength steel plates to improve its anti-torsion, anti-vibration and anti-turbulence capabilities to meet the operating needs of more complex road conditions.

● The floor adopts 4mm thickness wear-resistant and anti-slip pattern plate, which makes the transportation of bulk goods safer and more stable.

● The whole process of robot automatic tracking welding technology, the solder joints are dense and strong, and the weld seams are uniform and flawless.

● Use high-performance accessories of international famous brands to reduce maintenance costs.

● The whole vehicle is treated with shot blasting and sprayed with polyurethane paint, which is corrosion-resistant and has high gloss.

Specification:

Dimension(L*W*H): 13500x2500x3200mm

Tare Weight: about 8.5t

Loading Capacity: 60-100 ton

Main Beam: height 500mm, upper plate 14mm, middle plate 8mm, lower plate 16mm, material Q345B steel

Side Beam: 16mm or 18mm channel steel

Platform: 4 mm-thick checkered plate

Trailer Sidewall: 1000mm or customize

Axles: 4 axle*13T/16T*FUWA/BPW brand

Tire: 16 units*12.00R22.5 or 315/80R22.5

Rim: 9.00-22.5 steel wheel rim

Suspension: heavy duty mechanical suspension

Spring Leaf: 90(w)mmx13(thickness)mmx10 layers or 100mmx12mmx12 layers

King Pin: JOST brand 2.0 or 3.5 inch traction pin

Landing Gear: JOST brand

Twist Locks: 4/8/12 sets (lifting or screw type)

Brake Valve: WABCO valve

ABS: optional

Light: LED light

Voltage: 24V

Socket: 7-pin Socket (for 7 wire harness)

Painting: 1 layer of anticorrosive primer and 2 layers of top coats

Accessories: one tool box, spare tire carrier

Shipping Terms: bulk carrier, Ro-Ro ship or container

---
